The diagnostic method of claim 10 wherein the step of displaying includes the step of displaying all of the selected diagnostic parameters.ġ2.
Monitoring all of the vehicle diagnostic parameters andĭisplaying the condition of at least one selected diagnostic parameter on the display.ġ1. while the vehicle is in the normal operating mode:
Storing an indicator for each selected diagnostic parameter, each indicator identifying a corresponding selected diagnostic parameter andī. Manually selecting at least one of the diagnostic parameters while the vehicle is in the maintenance mode: In a material handling vehicle having a processor which executes a control program to operate the vehicle in either a maintenance mode or a normal operating mode, the vehicle including a display and characterized by a plurality of vehicle diagnostic parameters, a diagnostic method comprising the steps of:Ī.
#Raymond stand up forklift controls code
The improvement of claim 8 wherein the keypad can be used to enter an identification code and the improvement includes a means for interrogating an identification code and, where the identification code is acceptable, allowing an operator to alter the manually selected diagnostic parameters.ġ0. The improvement of claim 1 wherein the means for selecting is a keypad.ĩ. The improvement of claim 1 wherein the diagnostic parameters are indicated by both digital and analog information and the means for monitoring includes means for monitoring both digital and analog information.Ĩ. The improvement of claim 1 further including analyzing means receiving the at least one diagnostic parameter and determining the condition of the diagnostic parameter.ħ. The improvement of claim 4 wherein the display can only display one selected diagnostic parameter at a time.Ħ. The improvement of claim 1 wherein the display cannot simultaneously display all of the diagnostic parameters and the improvement further includes means for designating, during normal operating mode, which of the selected diagnostic parameters will be displayed.ĥ. The improvement of claim 1 wherein the processor also includes means for monitoring non-diagnostic vehicle parameters and the display also indicates the condition of at least one non-diagnostic parameter.Ĥ. The improvement of claim 1 wherein the display indicates the condition of each selected diagnostic parameter while the vehicle is in the normal operating mode.ģ. Means responsive to the stored-indicators for indicating the condition of at least one selected diagnostic parameter to the display while the vehicle is in the normal operating mode.Ģ. Means for storing an indicator for each selected diagnostic parameter, each indicator identifying a corresponding selected diagnostic parameter Ī display for indicating the condition of at least one of the selected diagnostic parameters and Means operable, while the vehicle is in the maintenance mode, for manually selecting at least one of the diagnostic parameters Means for monitoring a plurality of vehicle diagnostic parameters In a material handling vehicle having a processor which executes a control program to operate the vehicle in either a maintenance mode or a normal operating mode, the improvement therein comprising: Each system in the vehicle can be analyzed by selecting the proper maintenance code.ġ. The maintenance mode is divided into three diagnostic surveys: output controls, digital input measurements for analyzing switches and encoders, and analog input measurements for testing voltages and potentiometers. The vehicle is selected for maintenance diagnostics during the program mode, and then switched back to the normal operating mode, where the intermittent failures can be diagnosed. The program mode is divided into three additional modes: "maintenance mode", "configure mode" and "learn mode". The program mode can then be entered to assess just where the problem is located.
A fault code scrolls across the vehicle display screen, indicating the nature of the failure.
During the normal operating mode, the vehicle operator is warned of a problem by different audible tones and patterns. The program is divided into two vehicular modes, "normal operating" and "program". The microprocessor is programmed to analyze each system during normal vehicular operation. The material handling vehicle of this invention uses an on-board microprocessor and display to allow an operator to determine whether any intermittency is present in the internal systems. The present invention features a diagnostic method for assessing intermittent failures which occur in the components and systems of material handling vehicles.
